Carp Design Estart EV 200 Extend 40lbs Navigation Pack

Name: Carp Design Estart EV 200 Extend 40lbs Navigation Pack
Brand: Carp Design
SKU: esc16196
Price: 598.08 EUR
Availability: InStock
Rating: 4 (10 reviews)

[esc16196]

Rate: 4.7 - 18 votes

See reviews

Inspired by current trends and the needs of modern carp anglers, Carp Design is a rising brand which aims to bring a new vision of carp fishing tackle.

Carp Design Estart EV 200 Extend 40lbs Navigation Pack

663^€00598^€08

64^€92

In Stock

Shipping 24h

-5%

Free delivery

I saw this product for a lower price elsewhere.

contact

This product is part of the following categories:

Carp Design Estart EV 200 Extend 40lbs Navigation Pack

Carp Design Estart EV 200 Army Green Slat Floor Boat

The Estart 200 is a pneumatic boat designed according to rigorous specifications, meeting specific expectations in terms of safety and use.

This new "EV" version has some head-turning improvements! Its interior space has been increased by 20% with the dashboard set back and the two flanges spaced out. Soft grips replace the old hard grips. We have also added reinforcement strips on the underside. In short, this brand new boat is a little jewel!

Made from a 0.7mm PVC based on 1000D polyester Army Green color, it has two independent inflatable tubes with high pressure valves.

Carp

Easy to install, handle and transport thanks to its length of 200cm, it remains nonetheless habitable thanks to its optimized interior dimensions. It can be used on small waters as an annex in large lake with its tubes of 36cm in diameter.

The presence of a transom allows it to be easily motorized but also easily attach a support for echo sounder.

Carp

Those who practice the lines setting by boat know that the smaller the boat, the less stable it is!

To overcome this problem, we have expanded it to the maximum and designed in a form of "traditional" pneumatic (not shaped buoy) to make the same extremely stable when standing up to put the rig or kneeling on the tube during a fight!

It has a sliding bench which will be very useful when browsing with a motor, this will allow you among others to optimize the storage volume if you are carrying buckets full of pellets and boilies.

Carp

Because the boat will have to rub against rocks and other debris on the ground, we have provided with reinforcement strips under the side flanges and to ensure additional security, the eStart 200 has a line life all around the upper rim.

Incredibly versatile, it has everything to quickly become a "best-seller"!

Carp

New extended version
Marine wood slatted floor
Lifeline all around the boat
Number of slats: 2
Side straps for landing net or rod
Black aluminium slats for more discretion
Adjustable sliding bench in marine wood (removable)
0.7mm PVC with 1000D polyester base
Colour: Army Green
Number of chambers: 2
Stainless steel fixing ring on the front of the boat
Flange diameter: 36cm
8cm wide reinforcement strip under the side flanges
Reinforced transom
Anchor support at the bow
ISO6185 standard
Boat not registrable by the maritime affairs
Supplied complete with carry bag and inflator
Repair kit supplied

Interior dimensions: 145cm x 80cm

Dimensions: 200cm x 152cm - Weight: 23.8kg

Carp

Lifeline all around the boat

Carp

Colour: Army Green

Carp

Stainless steel fixing ring on the front of the boat

Carp

Side straps for landing net or rod

Carp

Black aluminium slats for more discretion

Carp

Reinforced transom

Carp

8cm wide reinforcement strip under the side flanges

Carp Design Estart+ Extend 40lbs 12V Electric Motor

For this new range of motors, we wanted to make our own contribution to the protection of the environment by selecting a production site with RoHS approval and under TÜV Rheinland certification.

The Estart+ Extend range is the logical evolution of our engines. Our experience in the field has enabled us to offer you a new series that is even more adapted to the needs and requirements of carp anglers.

The headbox has been completely redesigned to allow the handle to be tilted up to 45° which will make it easier to orientate the motor when you are standing in your boat during a fight, a trip or simply when you drop your rig. Its shaft is no longer telescopic but has been lengthened to make it as long as a fully extended telescopic shaft, making the experience even more comfortable.

The control box is still equipped with a 9-LED battery level indicator to avoid any inconvenience when you are on the water.

The Estart+ Extend has a trigger near the motor mount that allows you to tilt the motor with a simple push (9 positions), while a screw ring on the arm allows you to adjust the depth of immersion of the propeller.

They work with a 12V battery (battery not included) and are available in 3 different powers (40lbs, 58lbs and 66lbs) in order to be able to meet all the needs and adapt to each type of boat.

The power cables have clips at the ends so that we can connect the motor to the battery (battery not included) in a flash. For optimal use, we recommend that you use a marine battery (slow discharge of at least 70Ah) and above all that you wear a life jacket.

Control system: patented high current speed switch
Mounting system: 9 position mounting bracket
MOGEN carbon brush - double life
All aluminium carbon brush holder
Streamlined motor head
Professionally tested propeller angle
All copper rotor for better cooling effect long life all in operation
Improved fuel system
Porsche-inspired design
Tilt/Extend Tiler: Tilts (up to 45°) for maximum control
Powerful stand: made of aluminium composite, reliable at high speed
Level Lock Bracket: 10-position bracket features a quick-release lever lock and reinforced composite material that resists bending, warping and UV damage

Power: 40lbs
Thrust: 18.14kg
Speed control: Continuous
Motor type: Brushless direct drive motor
Rated voltage: 12V
Propeller depth adjustment: clamp
Propeller type: 3 blades
Number of forward speeds: 5
Number of reverse gears: 3
Rated speed (rpm): 1000
Rated current (A): 34Ah
Rated power (W): 408W
Control handle: fixed 15cm
Shaft length: 76.2cm
Maximum speed: 6-7km/h
Weight: 8.8kg
Dimensions: 100cm x 48cm x 16cm
Warranty: 2 years
Product designed with RoHS approvals
TÜV Rheinland certification

What is the RoHS directive?

The Restriction of Hazardous Substances (RoHS) Directive limits the use of ten hazardous substances commonly used in electrical and electronic equipment (EEE). The aim of the directive is twofold: to reduce pollution and prevent environmental damage caused by the restricted materials, for example during recycling or waste disposal, and to reduce the health risks associated with their exposure.

TÜV Rheinland certification: proof of quality for your products:

The independent body TÜV Rheinland checks that products comply with the relevant European regulations by affixing the CE mark as a guarantee of quality and conformity.
