Toslon X-Boat 730 Bait Boat + TF520 X-Pilot + Gift

Toslon X-Boat 730 Bait Boat + TF520 X-Pilot

Toslon X-Boat 730 Bait Boat

XBOAT is a smart remote control bait boat, which is generally used to help fisherman transporting baits to a target position on water. The streamline concept of Xboat shape design was from supercar and yacht. It integrated the handle into the body, which make it more fashionable and professional.

Xboat uses an industrial motor and DSS (double sealing system) water proof technique, which guarantee no water leaking even being used under bad water condition. And by using together with built-in GPS sonar fishfinder, Xboat can detect fishing condition in water area more than 500m away from the river bank.

The fishing condition includes water depth, water temperature, fish location, bottom condition, etc. And with GPS function, it can guarantee the user transporting baits to the same position every time. Which is very important during fishing. Moreover, the most attractive design for the Xboat is the controlling system. It integrated all electronic system into 2 boxes, ESC box and CCU box, which make it more stable and very easy for maintain.

What comes with every boat ordered:

• FlySky 2.4 Ghz 6 Channel Remote Control  (Optional Futaba T6K)
• 2 Li-Ion batteries x 12.000mAh / 12v - Enough power for 5 hours working time at max speed
• 1 Li-Ion Charger
• Well Padded bag for all bait boat acessories
• Well Padded Bag for X- Boat
• 2 Years International Warranty

• 2.4 GHz 6-channel remote control
• Up to 5kg bait capacity / Volume total 5 Liter ( 2.5 liters per hopper )
• Standard 2 Li-ion battery (12000 mah /12v) provide more than 4.5hours running time at max speed
• R/C Range 500m to 1000m, depending upon environmental conditions
• Special weeds protection
• Failsafe-system as standard
• Two separately controllable hopper releaseing
• Non-wearing and easy-to-use magnetic pin hook releasing system
• High performance industrial engines
• SONAR/GPS/Autopilot pre-designed. Easy Plug and Play without demaging the body
• State of the art elctronic control system provide top reliability even under the toughest conditions
• Special handle design with rubber protection providing comforatble grabing
• Unique shape design make the boat apperance attractive and remarkable

Dimensions : 70 cm x 44 cm x 27 cm - Poids 7 kg

High reliability

The innovative DSS (double seal system) technology, instead of single oil sealing, provides the most safe shaft sealing.

Heavy load hopper system use unique Sensor-less position control technique, always open close to correction position during all lifetime of the boat. The two specially designed hopper were made with 0.8mm stainless plate, provide a 32kg*cm torque

Smart Front Light

The 2 front light were designed with 2*30pcs small white LED and 2*1.5w high brightness LED ( switchable via the remote control independently). The dazzling light can clearly guide you the direction of boat no matter using day or night.

The brightness is adjustable via the remote control.

Water Switch

X-boat will power on automatically in 30s after putting it on water. And power off automatically after it was taken from water. Which prevent you losing your boat when you forgot powering on after putting it on water.

Battery security

The tail light will start blinking slowly if the battery energy is lower than 30%. The lower the battery energy is, the faster the tail light blink.

Supplied with a protection bag

• Range: 300m (variable depending on the environment)
• Depth capability: 30m (100ft)
• Wireless digital echo sounder
• Radio frequency: 2.4GHz
• RF chain: 20
• RC power: 20dBm
• Sonar frequency: 115kHz
• Sonar Beam Angle: 60 degrees @-10db
• Display size: 4.3" TFT LCD Sunlight Viewable
• Resolution: 480 x 272 pixels - 65,536 color
• DC 9~15V / 3S lithium battery
• Battery: 3S 18650 (sold separately)
• Multi-language menu (including French)
• Operating temperature: -10°C and +50°C
• Sensor Cable Length: 50cm

• IPX6 Level Waterproof Casing Design
• Water Temp. Included in Transducer
• Frequency-hopping spread spectrum (FHSS)
• Direct-sequence spread spectrum (DSSS)
• Hardware gain adjustable
• Built in 3S lithium battery charging function
• Stable wireless performance even in bad condition
• Full two-year warranty; extended warranties available
• Monitor and Display Real-time Voltage of Bait boat Battery

• Sonar Alarms: Fish / Shallow / Low Battery
• Real-time display (no time lag between what the echo picks up and what is displayed on the screen)
• Color Line technology allows for easy reading of fish and bottom structure (easily identifiable bottom hardness)
• Depth is indicated above each fish symbol
• Sonar alarm: fish, high bottom and low battery (boat battery and echo sounder battery)
• Depth sounder battery level and boat battery level display
• Easy to store with a foldable display in the housing
• Memory system to retain previously saved settings
• Freshwater/saltwater compatible
• 2 year warranty
• Switch for transmitter not included

Toslon X-pilot GPS Autopilot

As an autopilot system, TOSLON X-Pilot (TC106) can work with most bait boats. It support: 2 Engines / 1 Engine with Rudder / XBoat and using one button to start the auto-pilot mode. [Wiring Test] Menu help you check & correct connection quickly.

KEY FEATURES:

• 1. Boats support: 2 Engines / 1 Engine with Rudder / XBoat
• 2. Easy Operation: one button to start the auto-pilot mode
• 3. Easy Connection: [Wiring Test] Menu help you check & correct connection quickly
• 4. Radio Power: 100mW (max operating range: 800ft)
• 5. Storage: Micro-SD support, Max 500 fishing spots, and upgrade software by SD simplely
• 6. Quickly saving / loading waypoints (and HOME point)
• 7. Automatically steer straight ahead
• 8. Quickly fixed to remote with special metal bracket (optional)

• Display size: 4.3" FSTN,  Black & white
• Display resolution: 240x160 Pixels,Visible under sunlight
• Language: English (future update: German / French / Russian)
• Failing-safe: YES (the X-Pilot would alarm when lost the remot signal)
• SD card storage: YES
• Radio frequency: 433Mhz / 2GFSK
• Radio Power: 20dBm (Max 800ft RC distance , depending on weather
  and environmental conditions)
• Waypoints Number: 500
• Quick Reach Targets: 4 (include the Home position)
• GPS Receiver Type: 50 Channels
• Compass Update Range: 10Hz
• Power for X-Pilot CCU: DC 6~16V
• Power for the display: Li battery (BL-5C)




Tripod sold separately

Click here to download the user manual

Product presentation
