Anatec Pac Boat Start'R Camou Forest AN-i6X Bait Boat TF520 B + Gift

Anatec Pac Boat Start'R Camou Forest AN-i6X Bait Boat TF520 B

Anatec Pac Boat Start'R Camou Forest + AN-i6X Bait Boat

With its small size and surprising ease of use, the Pac Boat is the perfect beginner's boat.

Thanks to a higher deck, the waterline has been increased which improves buoyancy. At the same time, the capacity of the bait box has been increased from 1kg to 1.5kg.

Compared to its brothers (Monocoque S and Catamaran), the Pac Boat benefits from minimal dimensions and low weight for ease of transport and use.

The Pac Boat is designed to meet the growing demand of some users for whom a bait boat remains indispensable, but who do not wish to be burdened with a model that could hinder a more "mobile" approach to their fishing.

Some of Graupner's electronics have been replaced by standard components (speed controller and servo motor).

The AN-i6X remote control benefits from 2.4 GHz technology and is equipped with the AFHDS 2A (Automatic Frequency Hopping Digital System Second Generation) developed and patented by FLYSKY. Offering superior interference protection while maintaining low power consumption and reliable high sensitivity reception, FLYSKY's AFHDS technology is considered one of the leaders in the RC market today.

The Pac Boat's minimalist design gets to the heart of the matter, no unnecessary gimmicks, tensioning your lines and baiting your fishing spots with precision is the essential function of this boat that beginners will have no trouble getting the hang of.

It has a digital voltage monitor to check the battery voltage instantly.

Camo Wood model shown on pic

The Pac Boat is powered by a propeller motor and two 6V 4.5Ah lead batteries. The boat has a range of about 80 minutes and a maximum speed of 1.6m/sec.

The steering is provided by a rudder mechanism.

Located in the rear position, the Pac Boat's priming tank has a capacity of 1.5kg. This tray allows the transport of the bait and the line.

Camo Wood model shown on pic

Delivered complete with:

• 2 Batteries 6V / 5Ah
• 1 grease gun
• Charger included

Dimensions: 59cm x 28cm x 25cm - Weight: 4.5kg (including batteries)

On-Off Switch - Camo Wood model shown on pic

Propeller and rudder details

Bottom of the boat

AN-i6X Remote Control

This ANATEC AN-i6X remote control has been co-developed with the manufacturer FLYSKY, the reference on the model radio control market. This 6-channel radio control has an outstanding price-quality ratio and is very easy to use.

The AN-i6X transmitter and AN-i6X receiver form a 6-channel 2.4GHz AFHDS 2A digital proportional R/C system. (Upgradable to 10 channels)

The AFHDS 2A (Automatic Frequency Hopping Digital System Second Generation) developed and patented by FLYSKY. Offering superior interference protection while maintaining low power consumption and reliable high sensitivity reception, FLYSKY's AFHDS technology is considered one of the leaders in the RC market today.

Omnidirectional Gain Antenna

The high efficiency omni-directional high gain antenna reduces interference, while using less power and maintaining a strong, reliable connection.

Bi-directional communication

Capable of sending and receiving data, each transmitter is capable of receiving temperature, altitude and many other types of sensor data, servo calibration and i-BUS support.

Low power consumption

The system is built using highly sensitive, low power consumption components, maintaining high receiver sensitivity, while consuming as little as one tenth the power of a standard FM system, greatly extending battery life.

Unique identity recognition system

Each transmitter and receiver has its own unique ID. Once the transmitter and receiver have been paired, they will only communicate with each other, preventing other systems from accidentally connecting or interfering with the systems' operation.

Multi-channel hopping frequency

Click here for Additional Battery

• Range: 300m (variable depending on the environment)
• Depth capability: 30m (100ft)
• Wireless digital echo sounder
• Radio frequency: 2.4GHz
• RF chain: 20
• RC power: 20dBm
• Sonar frequency: 115kHz
• Sonar Beam Angle: 60 degrees @-10db
• Display size: 4.3" TFT LCD Sunlight Viewable
• Resolution: 480 x 272 pixels - 65,536 color
• DC 9~15V / 3S lithium battery
• Battery: x8 AA
• Multi-language menu (including French)
• Operating temperature: -10°C and +50°C
• Sensor Cable Length: 50cm

• IPX6 Level Waterproof Casing Design
• Water Temp. Included in Transducer
• Frequency-hopping spread spectrum (FHSS)
• Direct-sequence spread spectrum (DSSS)
• Hardware gain adjustable
• Built in 3S lithium battery charging function
• Stable wireless performance even in bad condition
• Full two-year warranty; extended warranties available
• Monitor and Display Real-time Voltage of Bait boat Battery

• Sonar Alarms: Fish / Shallow / Low Battery
• Real-time display (no time lag between what the echo picks up and what is displayed on the screen)
• Color Line technology allows for easy reading of fish and bottom structure (easily identifiable bottom hardness)
• Depth is indicated above each fish symbol
• Sonar alarm: fish, high bottom and low battery (boat battery and echo sounder battery)
• Depth sounder battery level and boat battery level display
• Easy to store with a foldable display in the housing
• Memory system to retain previously saved settings
• Freshwater/saltwater compatible
• 2 year warranty
• Switch for transmitter not included
