Anatec Monocoque S IVY AN-i6X Echo TF640 + Gift

AN-i6X Remote Control

This ANATEC AN-i6X remote control has been co-developed with the manufacturer FLYSKY, the reference on the model radio control market. This 6-channel radio control has an outstanding price-quality ratio and is very easy to use.

The AN-i6X transmitter and AN-i6X receiver form a 6-channel 2.4GHz AFHDS 2A digital proportional R/C system. (Upgradable to 10 channels)

The AFHDS 2A (Automatic Frequency Hopping Digital System Second Generation) developed and patented by FLYSKY. Offering superior interference protection while maintaining low power consumption and reliable high sensitivity reception, FLYSKY's AFHDS technology is considered one of the leaders in the RC market today.

Omnidirectional Gain Antenna

The high efficiency omni-directional high gain antenna reduces interference, while using less power and maintaining a strong, reliable connection.

Bi-directional communication

Capable of sending and receiving data, each transmitter is capable of receiving temperature, altitude and many other types of sensor data, servo calibration and i-BUS support.

Low power consumption

The system is built using highly sensitive, low power consumption components, maintaining high receiver sensitivity, while consuming as little as one tenth the power of a standard FM system, greatly extending battery life.

Unique identity recognition system

Each transmitter and receiver has its own unique ID. Once the transmitter and receiver have been paired, they will only communicate with each other, preventing other systems from accidentally connecting or interfering with the systems' operation.

Multi-channel hopping frequency

Toslon TF640 Colour + GPS + Compas + Sonar

Navigation Sonar system TF640 was specially designed for all kinds of bait boats. It was combined with high Position accuracy GPS, digital wireless sonar and electronic compass.

The GPS system let you guiding the boat to any waypoint you saved. The advanced sonar feature show you actual bottom condition and fish, and the electronic compass indicate the instant boat heading direction on screen which make it possible to operate the boat under bad condition, such as night, heave fog, etc.

This sounder is equiped with a newbrand GPS antenna wich comes directly into the baitboat meaning the antenna is protected from any external damage, for a safer use.

GPS Position Accuracy: 1m(filed test); RC Distance:300m; 500 Waypoint; Digital Wireless Sonar with 80ft depth range; Sonar frequency 455kHz; 4.3" TFT with resolution 480*272Pixels; 65,536 color;

GPS and COMPASS

• GPS data display show: Distance to target, Distance to Home,Speed of boat,Time to Board,Satellite
• Number,Heading,Bear, Course Memory,Time of day,Main Battery.
• Compass indicator of the instant boat heading direction on screen (a red "+" on screen indicate the target)
• Indicator of the position and distance to target waypoint and HOME
• Boat arriving alarm
• Signal lost alarm
• Indication of satellite condition by color bar: red(0~satellites); Yellow(3~6); Blue(?6)
• Show the current position as latitude/longitude in decimal degrees
• 20 RF channels allow different users operation at same region without interference
• Detailed waypoint information including icon, name, date, etc
• Zoom in/Out route display

Sonar :

• Adopt brand new digital wireless sonar system
• Real time sonar windows display the latest sonar returns
• Color Line separates fish and structure from the bottom, and defines bottom hardness.
• Display target depth reading above each fish symbol as a guide for quick and precise lure presentations.
• Sonar alarm: fish / shallow / low battery(boat battery and display battery)



Click here to download the user manual

Toslon 2200mAh 3S Internal Battery for Echosounder

This 11.1V Lithium-Ion battery has been specially developed to power the Toslon and Anatec echo sounder display cases.

This "internal" version of 2200mAh comes to be placed in the compartment located at the back of the screen and the supplied mains charger will allow you to recharge it via the socket present on the case of the echo sounder.

It is compatible with the following echo sounders: Anatec ALF500, Toslon TF520, TF520, TF640, TF650 and TF740
