Anatec Catamaran IVY AN-i6x Echo TF640 + Gift

The catamaran is the ultimate bowsprit, its typical shape ensuring perfect buoyancy and unfailing stability even in the most extreme conditions (wind and waves).

Located on each side of the hull, two ventilated motors provide the power needed to sail at more than 5 km/h under full load. The motors are controlled independently of each other, allowing the boat to be steered.

This feature ensures perfect manoeuvrability of the catamaran and gives it the ability to turn on the spot. This is a major advantage when the lines need to be laid with great precision (along edges or under foliage).

The catamaran is fitted with a handle for easy transport and launching.

Non-contractual image, illustration in another colour

The stainless steel priming tank is positioned centrally, giving the boat excellent stability even when loaded. It is divided into 2 compartments.

The remote control allows the hatches to be opened progressively, so that the fishing area can be sprayed. The 2 hatches can be opened independently for precise, targeted baiting.

The box can hold up to 5kg (2 x 2.5kg) and can be used to carry any type of groundbait (boilies, seeds, pellets, flours).

When it comes to depositing the lines, the assembly fits easily and reliably into the hatch. Laying is very precise and the rig is always fishable.

Non-contractual image, illustration in a different colour

For use at night or in bad weather, the catamaran is fitted with 6 ultra-powerful white LEDs at the bow and 2 red LEDs at the stern, so you can spot the boat's position even from a great distance.

For the outward and return journeys, the brightness of the LEDs gives you the direction. If the boat veers off course, the intensity of the LEDs decreases because you can no longer see them from the front.

In terms of autonomy, all the catamaran models are fitted with 2 lead-acid 6V/12A batteries, giving them a range of 90 minutes.

A digital battery charge indicator is located on the side of the boat. Information is given in Volt. If the indicator shows 6V, the batteries need to be recharged.

Main specifications:

• Dimensions: 85cm x 50cm x 25cm
• Charging capacity: 5kg
• Weight without batteries: 11kg
• Supplied complete with carry bag

Non-contractual image, illustration of another colour

• 1: Carrying handle
• 2: Removable cover
• 3: Hood fastener: Allows the bonnet to be held in place or removed in order to work on the ignitor's internal components
• 4: Front position LEDs: 6 white LEDs for viewing the boat at night or from a long distance
• 5: Rear position LED: 2 red LEDs for night-time or long-distance viewing of the boat
• 6: Location for echo sounder ON/OFF switch (sold separately)
• 7: Location for echo sounder antenna (sold separately)
• 8: Digital voltage controller

Handset AN-i6X remote control

This ANATEC AN-i6X radio control was co-developed with the manufacturer FLYSKY, the reference on the model radio control market. This 6-way radio control offers exceptional value for money and is very easy to use.

The AN-i6X transmitter and AN-i6X receiver constitute a 6-channel 2.4GHz AFHDS 2A digital proportional computerized R/C system. (Upgradable up to 10 channels)

AFHDS 2A (Automatic Frequency Hopping Digital System Second Generation) developed and patented by FLYSKY. Providing superior protection against interference while maintaining low power consumption and reliable high reception sensitivity, FLYSKY's AFHDS technology is considered one of the leaders in the RC market today.

Omnidirectional gain antenna

The high-efficiency, high-gain omnidirectional antenna reduces interference, while using less power and maintaining a strong, reliable connection.

Two-way communication

Capable of sending and receiving data, each transmitter is capable of receiving temperature, altitude and many other sensor types, servo calibration and i-BUS support.

Low energy consumption

The system is built using highly sensitive, low-power components, maintaining high receiver sensitivity, while consuming as little as one-tenth the power of a standard FM system, greatly extending the operating time. battery life.

Unique identity recognition system

Each transmitter and receiver has its own unique ID. Once the transmitter and receiver have been paired, they will only communicate with each other, preventing other systems from accidentally connecting or interfering with the systems operation.

Multi-channel hopping frequency

The bandwidth of this system ranges from 2.408 GHz to 2.475 GHz. This band is divided into 135 channels. Each transmitter jumps between 16 channels to reduce interference from other transmitters.



Toslon TF640 Colour + GPS + Compas + Sonar

Navigation Sonar system TF640 was specially designed for all kinds of bait boats. It was combined with high Position accuracy GPS, digital wireless sonar and electronic compass.

The GPS system let you guiding the boat to any waypoint you saved. The advanced sonar feature show you actual bottom condition and fish, and the electronic compass indicate the instant boat heading direction on screen which make it possible to operate the boat under bad condition, such as night, heave fog, etc.

This sounder is equiped with a newbrand GPS antenna wich comes directly into the baitboat meaning the antenna is protected from any external damage, for a safer use.

GPS Position Accuracy: 1m(filed test); RC Distance:300m; 500 Waypoint; Digital Wireless Sonar with 80ft depth range; Sonar frequency 455kHz; 4.3" TFT with resolution 480*272Pixels; 65,536 color;



GPS and COMPASS

• GPS data display show: Distance to target, Distance to Home,Speed of boat,Time to Board,Satellite
• Number,Heading,Bear, Course Memory,Time of day,Main Battery.
• Compass indicator of the instant boat heading direction on screen (a red "+" on screen indicate the target)
• Indicator of the position and distance to target waypoint and HOME
• Boat arriving alarm
• Signal lost alarm
• Indication of satellite condition by color bar: red(0~satellites); Yellow(3~6); Blue(?6)
• Show the current position as latitude/longitude in decimal degrees
• 20 RF channels allow different users operation at same region without interference
• Detailed waypoint information including icon, name, date, etc
• Zoom in/Out route display

Sonar :

• Adopt brand new digital wireless sonar system
• Real time sonar windows display the latest sonar returns
• Color Line separates fish and structure from the bottom, and defines bottom hardness.
• Display target depth reading above each fish symbol as a guide for quick and precise lure presentations.
• Sonar alarm: fish / shallow / low battery(boat battery and display battery)



Click here to download the user manual

Toslon 2200mAh 3S Internal Battery for Echosounder

This 11.1V Lithium-Ion battery has been specially developed to power the Toslon and Anatec echo sounder display cases.

This "internal" version of 2200mAh comes to be placed in the compartment located at the back of the screen and the supplied mains charger will allow you to recharge it via the socket present on the case of the echo sounder.

It is compatible with the following echo sounders: Anatec ALF500, Toslon TF520, TF520, TF640, TF650 and TF740
